Digiphoto – Photography Light – 450Bi

FX Modes Table

Matters need attention

• For indoor use, the use environment should be kept dry and ventilated.
• There should be no water or other liquid dripping into the product during use, so as not to cause short circuit of the internal circuit and damage the product.
• Do not use more than the rated voltage.
• A slight heat in the lamp body is normal.
• When moving or installing, handle gently and do not impact other objects, so as to avoid deformation of the lamp shade or damage to the lamp body.
• When the LED light is on, do not look directly at it, the light is too strong to avoid damage to the eye.
• Avoid placing lights near flammable or volatile solvents such as alcohol or gasoline.
• Please use a soft dry cloth to clean the camera light. You can lightly dip the cloth with some neutral cleaner to wipe off the dirt that is difficult to remove, and then wipe it dry with a soft cloth.
• Do not keep this product near children.
• Non-professionals, please do not disassemble, otherwise the consequences are their own.
• Please cut off the power when the COB camera light is not used for a long time.
• Please observe this note, otherwise it may cause injury.

Product Function Description

• Product Power On: After the product is powered on, turn the red power button, the display lights up, the lamp beads light up and the product works.
• Brightness Adjustment: Adjust the “Brightness Knob Control” clockwise, can turn the brightness of the light from 0-100%.
• CCT Adjustment: Rotate the “CCT / Lighting Mode Knob Control” clockwise, the CCT of the light will be changed from 2700-6500k, the corresponding CCT will be displayed in the lower right corner of the screen.
• Mode Switch:
  ① Press the “CCT / Lighting Mode Knob Control” once, the lower left corner of the screen lights up FX01, then turn the knob left and right to choose from 12 special effect modes FX01-12. In this mode, brightness can also be adjusted from 10 to 100%. Each FX mode has 3 different type of change speed, you can click the FX button on the remote to control it.
  ② Press the “CCT / Lighting Mode Knob Control” again to enter the “ISL One Click Intelligent Lighting mode”, the corresponding icon will appear in the top right corner of the screen (see the table below), turn the knob left and right to switch between the previous/next mode, the brightness can also be adjusted in this mode.
  ③ Press the “CCT / Lighting Mode Knob Control” three times to return to the CCT mode, and so on.
